Hard alloy saw blade-for common wood

 Manufacturing process: brazed
Material: 65Mn, tungsten carbide

Finish: bright, Cr-plated, Ni-plated

Diameter: 110-500mm, 4-20inch
¡¡
D Thickness H Teeth width Teeth number Teeth type
110 1.2 20 2 24/30/40 ZY
150 1.2 20 2 24/30/40 ZY
180 1.5 20 2.4 24/36/40/60 ZY
230 1.8 25.4/30 2.4 36/40/60 ZY
255 2 25.4/30 2.8 36/40/60/80/100 ZY
305 2 25.4/30 2.8 40/60/80//120 ZY
305 2.2 25.4/30 3 60/80//100/120 ZY
355 2.5 25.4/30 3.2 60/80//100/120 ZY
405 2.5 25.4/30 3.2 60/80//100/120 ZY
405 2.5 25.4/30 3.2 60/80//100/120 ZY
455 2.5 30/32 3.2 60/80//100/120 ZY
500 2.5 25.4/30 3.2 60/80//100/120 ZY
